VOCOM Specifications
| VOCOM 2+ Tough | VOCOM II Tough | VOCOM 2+ Mini | VOCOM II Mini | |
|---|---|---|---|---|
| Computer operating system | Windows 10/11 (32/64 bit) | Windows 10/11 (32/64 bit) | Windows 10/11 (32/64 bit) | Windows 10/11 (32/64 bit) |
| Computer connection | USB or Wi-Fi | USB or Wi-Fi | Wi-Fi | Wi-Fi |
| Wi-Fi support | IEEE 802.11 a/b/g/n 2.4 Ghz and 5 Ghz | IEEE 802.11 a/b/g/n 2.4 Ghz and 5 Ghz | IEEE 802.11 a/b/g/n 2.4 Ghz and 5 Ghz | IEEE 802.11 a/b/g/n 2.4 Ghz and 5 Ghz |
| Wi-Fi security | Authentication: PSK, EAP-PEAP, EAP-TLS. Encryption: WPA2 only | Authentication: PSK, EAP-PEAP, EAP-TLS. Encryption: WPA, WPA/WPA2, WPA2 | Authentication: PSK, EAP-PEAP, EAP-TLS. Encryption: WPA2 only | Authentication: PSK, EAP-PEAP, EAP-TLS. Encryption: WPA, WPA/WPA2, WPA2 |
| Diagnostic application interfaces | RP1210C, J2534, J2534-1 | RP1210C, J2534, J2534-1 | RP1210C, J2534, J2534-1 | RP1210C, J2534, J2534-1 |
| Vehicle battery | 12 V or 24 V | 12 V or 24 V | 12 V or 24 V | 12 V or 24 V |
| Vehicle electronic architecture | Legacy Version 2 Version 3 Version 4 T1 Version 4 T2 | Legacy Version 2 Version 3 Version 4 T1 Version 4 T2 | Version 2 Version 3 Version 4 T1 | Version 2 Version 3 Version 4 T1 |
| Vehicle connection (*using OBD2 adapter) | OBD2, 9-Pin, 6-Pin, FCI, MEFI, BNA* | OBD2, 9-Pin, 6-Pin, FCI, MEFI, BNA* | OBD2, 9-Pin* | OBD2, 9-Pin* |
| Vehicle interfaces | 2xCAN (max. 1 Mbps) 1xJ1708 (max. 115 Kbps) 1xK-Line (max. 115 Kbps) 1xEthernet (max. 100 Mbps) | 2xCAN (max. 1 Mbps) 1xJ1708 (max. 115 Kbps) 1xK-Line (max. 115 Kbps) 1xEthernet (max. 100 Mbps) | 2xCAN (max. 1 Mbps) 1xJ1708 (max. 38 Kbps) | 2xCAN (max. 1 Mbps) 1xJ1708 (max. 38 Kbps) |
| Vehicle communication protocols | ISO 11898 ISO 15765-2 SAE J1939 SAE J1708 ISO 13400-2 ISO 9141 KWP 2000 Knorr/Wabco ABS NIRA EDC1 Volvo Penta MEFI BOSCH EDC J1708 DIS Geartronic SL2Q/Free Running | ISO 11898 ISO 15765-2 SAE J1939 SAE J1708 ISO 13400-2 ISO 9141 KWP 2000 Knorr/Wabco ABS NIRA EDC1 Volvo Penta MEFI BOSCH EDC J1708 DIS Geartronic SL2Q/Free Running | ISO 11898 ISO 15765-2 SAE J1939 SAE J1708 ISO 13400-2 | ISO 11898 ISO 15765-2 SAE J1939 SAE J1708 |
| Operating voltage | 6 V to 32 V (max. 36 V) | 6 V to 32 V (max. 36 V) | 6 V to 32 V (max. 36 V) | 6 V to 32 V (max. 36 V) |
| Operating ambient temperature | -40 °C to +85 °C -40 °F to +185 °F | -40 °C to +85 °C -40 °F to +185 °F | -40 °C to +70 °C -40 °F to +158 °F | -40 °C to +70 °C -40 °F to +158 °F |
| Ingress protection rating | IP67 | IP67 | IP44 | IP44 |
| Weight | 404 grams 14.25 ounces | 400 grams 14.1 ounces | 85 grams 3 ounces | 85 grams 3 ounces |
| Dimensions (WxDxH) | 160 mm x 91 mm x 44 mm 6.30 in x 3.58 in x 1.73 in | 160 mm x 91 mm x 44 mm 6.30 in x 3.58 in x 1.73 in | 110 mm x 47 mm x 22 mm 4.33 in x 1.85 in x 0.86 in | 110 mm x 47 mm x 22 mm 4.33 in x 1.85 in x 0.86 in |
